Basic kit for improving the performance of Hemi Predator Engines. Simple to install, you can expect significant performance increases.Kit Includes:
Basic kit for improving the performance of Tillotson, Honda and Clones Engines. Simple to install, you can expect significant performance increases. For Non Hemi Only Kit Includes:
Basic kit for improving the performance of GX390s, 420 Predators, 13/15 hp Chinese OHVs. Simple to install, you can expect significant performance increases.
Stage 1 Kit includes
· Race/Open Air Filter & Adapter,
· Main Jet for Application (see Notes)
· Pilot Jet
· Choke Hold Down Bracket
· Choice Of Header/Exhaust
Picture for reference only and may show optional parts. See above description for actual content.
Filter should be sprayed with K&N type oil, especially in dirt applications. Oil not included
Billet Aluminum flywheel recommended. Stock flywheels, esp "Clone" are prone to failure and very DANGEROUS
Note: UT2s series Hondas (2012 & up) have Rev Limited coils and will require a new coil to exceed 4000 rpm. The UT2 coils (4 wire) can only be used with stock flywheels or 6693 ARC flywheels. If using any other Flywheels, you must run a UT1 style coil (single wire). Most 390 “clone”, 420s, and 460s have UT1 style coils already (However some Lifans and 420s have a rev-limited digital ignition)
The difference in the Kits is the main jet. We recommend you check the check your STOCK main . If stock main is a :
· #92 thru 97, use a UT1 kit,
· #98 thru #102 use a Hemi Kit’
· >102, Use a UT2 kit
Manufacturers have been know to use different jets on the same models. So it is important to know the stock jet size
Our New Rotating Assembly Is Designed For The Predator 212 Hemi To Increase Displacement To 223cc
The Predator Hemi Has A Shorter Deck Height Than Most Other Honda-Based Clone Engines. Due To The Deck Height, It Was Difficult To Use Current Aftermarket Components With The 58mm Stroker Crank In This Block. Usually, Stroking The Engine Required Clearance Of The Rod, Cam, Crank, And Piston For Fitment. We Have Resolved These Issues With Our 58mm Stroker Kit For The Predator Hemi.
Kit Components:
Wildcat 223cc, 70mm Flat Top Piston- The Wildcat Piston Provides Clearance Between The Crank’s Counterweights and Piston Skirt. The Wildcat Piston Is Also Lighter Due To The Different Designs. The Piston Comes As A Complete Assembly With Rings, Wrist Pins, And Circlips.
EC Pinnacle Forged Rod- The Forged Rod Is Shorter Than Stock To Set The Flat Top Piston At Zero Deck Height (Some Variance May Be Expected with Mass-Produced Blocks.) Unlike Many Other Rods, The Dipper Doesn’t Interfere With The Cam Core, Making Installation Easier.
Wildcat 58mm Crankshaft- the Crankshaft Is the Same Used EC236R And The Wildcat 223 Engine. The Crankshaft Should Only Require Clearance Matching With The Camshaft, Depending On The Lobe Profile And The Compression Release. The Crankshaft Also Using The Honda / Clone Tapered Flywheel; The Hemi Flywheels Will Not Work. We Recommend Using Our SK200 Rev Wheel.
The Purpose Of This Kit Is To Offer More Displacement To Predator 212 Hemi For Classes That Are Limited To Predator Brand Engines.
This Kit Is A MUST If You Are Removing The Governor From The Motor. Our Next Level Of Performance Kit. This Kit Gives You All Of The Basic From Our Level One But Adds More Durability And Performance. This Kit Yields Over 10H! Kit Includes:
This Kit Is A MUST If You Are Removing The Governor From The Motor. Our Next Level Of Performance Kit. This Kit Gives You All Of The Basic From Our Level One But Adds More Durability And Performance. This Yields Approximate 10 HP. Kit Includes:
This Kit Is A MUST If You Are Removing The Governor From The Motor. Our Next Level Of Performance Kit. This Kit Gives You All Of The Basic From Our Level One But Adds More Durability And Performance. This Kit Yields Over 10hp! Kit Includes:
When You're Ready To Play With The Big Dogs But Don't want To Break The Bank. This Inclusive Kit Comes With Everything Needed To Double Horsepower And RPM Capability Of Your Motor To About 12hp. NOTE:This Is Not A Drop In Kit And Requires Mechanical Knowledge! Some Engines May Require Additional machining and Clearance, Especially Hemi Motors. Kit Includes:
When You're Ready To Play With The Big Dogs But Don't want To Break The Bank. This Inclusive Kit Comes With Everything Needed To Double Horsepower And RPM Capability Of Your Motor Of Your Motor To About 12hp. NOTE:This Is Not A Drop In Kit And Requires Mechanical Knowledge! Some Engines May Require Additional machining and Clearance, Especially Hemi Motors. Kit Includes:
